TND(SVC) Series Of Single-Phase High-Precision Automatic Ac Voltage Regulator
TND (SVC) series single-phase high precision automatic AC regulator, composed of contact autocoupling regulator, servo motor, automatic control circuit, etc. When the voltage of the power grid is unstable or the load changes, the automatic sampling control circuit sends a signal to drive the servo motor, and the position of the carbon brush of the network regulator, so that the power transmission is adjusted to the rated value and reaches a stable state.
Specification of TND(SVC) Series Of Single-Phase High-Precision Automatic Ac Voltage Regulator
| Performance | Technical Parameters |
| Incoming Voltage | 150V-250V |
| Output Voltage | 220V+3%, 110V+3% |
| Frequency | 50HZ/60HZ |
| Adjustment Time | <1Seconcd (when input voltage changes by 10%) |
| Efficiency | >90% |
| Ambient Temperature | -10, C~4-40, C |
| Relative Humidity | <90% |
| Waveform Distortion | No additional waveform distortion is found |
| Load Power | 0.8 |
| Absolute Resistor | >5MQ |
